Weldall operates a full range of CNC press brakes from 175 tons to 2,000 tons, allowing us to handle heavy-duty forming, long-length bending, and tight-tolerance work. Our equipment is built for large components and complex parts, delivering consistent precision across a wide range of materials and thicknesses.
Pullmax Optima 1800 CNC Press Brake
- 2,000 tons
- 21 feet Bed Length
- 40″ Throat
- Automatic ram leveling
- Thickness compensation and deflection compensation
- Capable of forming 1-1/4″ grade 50 carbon plate over the full 21′ length of the bed.
- Capable of forming up to 4” material in narrower sizes.
Pullmax 1375 Ton CNC Press Brake
- 1375 tons
- 30 feet Bed Length
- 49″ Throat
- Programmable back gauge
- Hydraulic front support brackets with followers
- Automatic ram leveling
- Thickness compensation and deflection compensation
- Capable of forming ¾” grade 50 carbon plate over the full 30’ length of the bed.
- Capable of forming up to 3” material in narrower sizes.
Ursviken Optima Series – 700 Ton CNC Press Brake
- 700 tons capacity
- 20′ bed length
- Automatic Variable Bottom Die
- Automatic Crowning
- CNC-Controlled Back Guage
- CNC Plate Support Lifts
- Hydraulic Tool Clamping
- Tool Storage Magazine
- Safety System: Laser Safe (front) + Rear Light Curtain
Cincinnati 350 Ton Press Brake
- 350 ton capacity
- 14 foot bed
- Programmable back gauge
- Auto Crown option for straight forming
- Adaptive Autoform for variances in material thickness and tensile strength
- Off line programming
Cincinnati 175 Ton CNC Press Brake
- 175 ton capacity
- 12 foot bed
- Programmable back gauge
- Auto Crown option for straight forming
- Adaptive Auto form for variances in material thickness and tensile strength
- Off line programming
